Onyx

onyx 43b

The large tanks capacity mixed with the small machine dimensions allows the machine to work in small environments with a long lasting work autonomy. The recovery tank can be drained using the special drain hose.

The distinctive element is the squeegee which is indeed provided with a system that allows the complete right and left rotation, allowing the operator to colect water even moving backwards.

The handlebar height can be adjusted and it is possibile to bend it completely for an easy transport of the machine. In that position even every maintenance intervention on the brush or on the squeegee will be significantly easier.


Theoretical productivity: 1500 m2/h
Characteristics
Walk behind machine without traction
Walk behind machine without traction
Power supply 24V/34Ah
Power supply 24V/34Ah
Cleaning width 430mm
Cleaning width 430mm
Brushes pressure 35kg
Brushes pressure 35kg
Battery autonomy 75min
Battery autonomy 75min
Solution tank / recovery tank 23/23l
Solution tank / recovery tank 23/23l
Disc brush 1x430mm
Disc brush 1x430mm
Brushes speed 150rpm
Brushes speed 150rpm
Technical data
Squeegee width
510 mm
Brushes motor
450 Watt
Motion system
semiautomatic
Maximum gradient
2%
Suction motor
300 Watt
Suction vacuum
82 mbar
Machine length
793 mm
Machine width
480 mm
Machine height
600 mm
Machine weight (with battery)
86.5 kg
Batteries compartment length
207 mm
Batteries compartment height
210 mm
Class
|
Protection level
IP 23
oudness
<70 dB (A)
Brushes and pad holder
Brushes
Material: PPL <br />Ø brush: 430 mm <br />Ø bristle:0,6 mm <br />Cod: 48903120
Material: PPL
Ø brush: 430 mm
Ø bristle:0,6 mm
Cod: 48903120
Material: PPL <br />Ø brush: 430 mm <br />Ø bristle:0,9 mm <br />Cod: 48903130
Material: PPL
Ø brush: 430 mm
Ø bristle:0,9 mm
Cod: 48903130
Material: Mix 5 <br />Ø disc: 430 mm <br />Cod: 48903150
Material: Mix 5
Ø disc: 430 mm
Cod: 48903150
Material: abrasive bristles <br />Ø brush: 430 mm <br />Ø :1,2 mm <br />Cod: 48903140
Material: abrasive bristles
Ø brush: 430 mm
Ø :1,2 mm
Cod: 48903140
Pad Holder
Pad holder<br />Ø disc: 425 mm <br />Cod: 48803020
Pad holder
Ø disc: 425 mm
Cod: 48803020
Pad holder cl green<br />Ø disc: 425 mm <br />Cod: 48803050
Pad holder cl green
Ø disc: 425 mm
Cod: 48803050
Accessories
Splash guard onyx 43
Splash guard onyx 43
Elastic for onyx
Elastic for onyx
Hose water load
Hose water load
EquipmentOptional:
Ozone system+
Ozone system
