Topaz

topaz 90

The TOPAZ 90 scrubber is equipped with two counter rotating disc brushes and is 36V powered. Thanks its AC traction wheel it offers great performances when climbing ramps combined with a quick maintenance.

TOPAZ 90 makes the ergonomics one of its main strength. Thanks to the adjustable seat, steering wheel and footboard, the operator can choose between several driving positions.
The design combines the advantages of the compactness to request of a 180 liters tank capacity.

TOPAZ 90 can be provided with several optional equipment such as the Detergent Solution System (3SD), the TELEMATICS system and the side brooms supports.

Theoretical productivity: 6750 m²/h

Characteristics

Ride-on machine with traction

Power supply 36V/320Ah

Cleaning width 900 mm

Brushes pressure adjustable max.140kg

Battery autonomy 3,5-4,5h

Solution tank / recovery tank 180/190l

Disc brushes 2x460mm

Brushes speed: 190 rpm

Technical data

Squeegee width

1100 mm

Brushes motor

2x700 Watt

Motion system

automatic

Maximum gradient

10%

Suction motor

2x570 Watt

Suction vacuum

190 mbar

Machine length

1962 mm

Machine width

985 mm

Machine height with rollbar

1865 mm

Machine height without rollbar

1613 mm

Machine weight w/o battery

453 kg

Traction motor

1200 Watt

Maximum forward speed

7 km/h

Batteries compartment length

620 mm

Batteries compartment width

540 mm

Batteries compartment height

460 mm

Class

|||

Protection level

IP X3

oudness

<70 dB (A)

Brushes and pad holder

Brushes

Material: PPL<br />Ø brush: 460 mm<br />Ø bristle: 0,3 mm <br />Cod: 48916010

Material: PPL
Ø brush: 460 mm
Ø bristle: 0,3 mm
Cod: 48916010

Material: PPL<br />Ø brush: 460 mm<br />Ø bristle: 0,6 mm <br />Cod: 48916020

Material: PPL
Ø brush: 460 mm
Ø bristle: 0,6 mm
Cod: 48916020

Material: PPL<br />Ø brush: 460 mm<br />Ø bristle: 0,9 mm <br />Cod: 48916030

Material: PPL
Ø brush: 460 mm
Ø bristle: 0,9 mm
Cod: 48916030

Material: Mix 5<br />Ø brush: 460 mm <br />Cod: 48916050

Material: Mix 5
Ø brush: 460 mm
Cod: 48916050

Material: abrasive bristles<br />Ø brush: 460 mm<br />Ø bristle: 1,2 mm <br />Cod: 48916040

Material: abrasive bristles
Ø brush: 460 mm
Ø bristle: 1,2 mm
Cod: 48916040

Pad Holder

Pad holder cl green
Ø disc: 460 mm
Cod: 48816020

Batteries and chargers

36V 320Ah5 tubular battery

36V/40A high frequency lead battery charger (500Ah5)

Accessories

Coupling assembly accessories

Softer rear wheel 70SH

Equipment Standard equipment:

Optional:

Download

Use & Maintenance Product sheet
