Aries 70

Powerful and robust.
Aries 70 is the first walk-behind floor-cleaning machine designed by Adiatek.

Two front trays facilitate emptying operations by the operator: the two trays have a low weight with a full load, an important factor when having to clean outdoor yards or environments with sand and other high-density materials. The trays are also visible with a simple locking and extraction system that does not require lifting or removal of any parts for unloading operations.

The broad dashboard has all the machine’s controls indicated with symbols that are easy and intuitive to understand and that allow the operator to easily approach the job.

The machine is equipped with a dual-wing electric filter shaker that allows for spreading the impulse on a broad surface for effective removal of dust from the panel filter.
Theoretical productivity: 3150 m2/h
Walk behind Sweeper
Walk behind Sweeper
Power supply 24V/110Ah
Power supply 24V/110Ah
Central brush<br />
cleaning path: 700 mm<br />
Side brush<br />
cleaning path: 900 mm
Central brush
cleaning path: 700 mm
Side brush
cleaning path: 900 mm
Filtering surface of filter: 2.5 m<sup>2</sup>
Filtering surface of filter: 2.5 m2
Battery autonomy 11h
Battery autonomy 11h
Number of collection trays: 2<br />
Total collection volume: 50l
Number of collection trays: 2
Total collection volume: 50l
Cylindrical brush Ø 240 mm
Cylindrical brush Ø 240 mm
Brush speed: 220 rpm
Brush speed: 220 rpm
Technical data
Collection tray volume
25 l
Total collection volume
50 l
Emptying system
Traction motor
95 Watt
Brush gearmotor
75 Watt
Suction motor
75 Watt
Type of filter
Paper filter
Maximum speed
3,5 km/h
Maximum gradient
Machine weight w/o battery
105 Kg
Machine width
914 mm
Machine length
1390 mm
Height (at the handlebars)
970 mm
