Topaz

topaz 85s

With TOPAZ 85s, Adiatek brings a new sweeping machine in the market, taking all the autonomy and ergonomics standards of the scrubbing version.

This model is equipped with an 85cm brushes base and a side brush, thanks to which the dirt is collected also along walls and corners, moving it under the machine to be collected in the dedicated van.

The machine is provided with a 3S dosing system as standard equipment, the possibility to adjust the brushes base pressure on 8 levels depending on how much the brushes are worn and also the chance to choose between the standard and quiet mode for the suction motor.

TOPAZ 85s can be equipped with several optional equipment as the water and detergent dosing system (3SD system), the TELEMATICS and the side brooms supports.
Theoretical productivity: 6375 m2/h
Characteristics
Ride-on machine with traction
Ride-on machine with traction
Power supply 36V/320Ah
Power supply 36V/320Ah
Cleaning width 850mm
Cleaning width 850mm
Brushes pressure adjustable - - -
Brushes pressure adjustable - - -
Battery autonomy 3,5-4,5h
Battery autonomy 3,5-4,5h
Solution tank / recovery tank 180/190l
Solution tank / recovery tank 180/190l
Cylindrical brushes 2x150mm
Cylindrical brushes 2x150mm
Brushes speed 785rpm
Brushes speed 785rpm
Technical data
Squeegee width
1100 mm
Brushes motor
2x650 Watt
Motion system
automatic
Maximum gradient
10%
Suction motor
2x570 Watt
Suction vacuum
190 mbar
Machine length
1962 mm
Machine width
985 mm
Machine height with rollbar
1865 mm
Machine height without rollbar
1613 mm
Machine weight w/o battery
445 kg
Traction motor
1200 Watt
Maximum forward speed
7.5 km/h
Batteries compartment length
620 mm
Batteries compartment width
540 mm
Batteries compartment height
460 mm
Class
|||
Protection level
IP X3
oudness
<70 dB (A)
Brushes and pad holder
Brushes
Material: NYLON<br />Ø brush: 150 mm <br />Length: 800 mm<br />Ø bristle: 0,3 mm <br />Cod: 48906090
Material: NYLON
Ø brush: 150 mm
Length: 800 mm
Ø bristle: 0,3 mm
Cod: 48906090
Material: PPL<br />Ø brush: 150 mm <br />Length: 800 mm<br />Ø bristle: 0,7 mm <br />Cod: 48906010
Material: PPL
Ø brush: 150 mm
Length: 800 mm
Ø bristle: 0,7 mm
Cod: 48906010
Material: PPL<br />Ø brush: 150 mm <br />Length: 800 mm<br />Ø bristle: 1 mm <br />Cod: 48906050
Material: PPL
Ø brush: 150 mm
Length: 800 mm
Ø bristle: 1 mm
Cod: 48906050
Material: abrasive bristles<br />Ø brush: 150 mm <br />Length: 800 mm <br />Cod: 48906070
Material: abrasive bristles
Ø brush: 150 mm
Length: 800 mm
Cod: 48906070
Material: PPL long bristles<br />Ø brush: 500 mm <br />Ø bristle:0,6 mm <br />Cod: 48916100
Material: PPL long bristles
Ø brush: 500 mm
Ø bristle:0,6 mm
Cod: 48916100
Batteries and chargers
36V 320Ah5 tubular battery
36V 320Ah5 tubular battery
36V/40A high frequency lead battery charger (500Ah5)
36V/40A high frequency lead battery charger (500Ah5)
Accessories
Coupling assembly accessories
Coupling assembly accessories
Softer rear wheel 70SH
Softer rear wheel 70SH
Equipment Standard equipment:
3S system+
3S system
Optional:
3SD system+
3SD system
Ozone system+
Ozone system
3SD Ozone system+
3SD Ozone system
