diamond 100 / 100p AC

diamond 100 / 100p AC
Theoretical working capacity: 7000 m2/h
AC traction wheel model, equipped with two counter rotating disc brushes with a 100cm cleaning width.
Request information

PRODUCT SPECIFICATIONS

Ride-on machine with traction Ride-on machine with traction
Power supply 36V/500Ah Power supply 36V/500Ah
Cleaning width 1000mm Cleaning width 1000mm
Brushes pressure adjustable max.160kg Brushes pressure adjustable max.160kg
Battery autonomy 5-7h Battery autonomy 5-7h
Solution tank / recovery tank 235/250l Solution tank / recovery tank 235/250l
Disc brushes 2x510mm Disc brushes 2x510mm
Brushes speed 162rpm Brushes speed 162rpm

According to 196/03 law, the collected data will be only used to inform customers about Adiatek S.r.l. activities and will be considered secret. Data introduction is optional, but we can’t give services without personal information. Owner of data treatment is Adiatek S.r.l. - Via Monte Pastello 14, 37057 San Giovanni Lupatoto (Verona) - Italy.

AC traction wheel model, equipped with two counter rotating  disc brushes with a 100cm cleaning width.

Like in all the diamond models, a knob on the dashboard is used to electronically select the weight applied by the brushes, for a value up to 160Kg.

It is a professional machine, easy to maintain. A stainless steel inspection hatch allows the complete cleaning of the recovery tank.
Thanks to its innovative shape, the strong squeegee dries perfectly even when driving at high speed; it is also possible to easily adjust and disassemble it and the rubbers can be used on both the edges.
The perfect weights balance grants safety, reliability and high performances. This is a machine indicated to clean very dirty or even slippery floors, where a quick cleaning is needed without compromising the quality of the result.

Thanks to its AC traction wheel, the diamond machine requires a reduced maintenance related to the motor, which goes hand in hand with great performances both when starting to drive and when driving over ramps.
Click here to download the product sheet
- Squeegee width: 1175 mm
- Brushes motor: 2000 Watt
- Motion system: automatic
- Maximum gradient: 10%
- Suction motor: 2x570 Watt
- Suction vacuum: 190 mbar
- Machine dimensions: L: 2025 mm
  W: 1040 mm
with rollbar H: 1685 mm
without rollbar H: 1330 mm
- Machine weight w/o battery: 600 kg
- Traction motor: 1200 Watt
AC: 1400 Watt
- Movement speed: 7 km/h
AC: 9 km/h
- Battery compartment: L: 640 mm
  W: 655 mm
  H: 530 mm
- Class: III
- Protection level: IP 23
- Loudness: <70 dB (A)

Quick guide

There you can download the machine’s quick guide.
We always recommend to read the complete Use&Maintenance manual.

diamond 100_IT quick guide

diamond 100_EN quick guide

diamond 100_F quick guide

diamond 100_D quick guide

diamond 100_E quick guide



Use & Maintenance manual

There you can download the Use & Maintenance manual.

Use & Maintenance manual
