diamond 100s AC

diamond 100s AC
Theoretical working capacity: 7000 m2/h
AC traction wheel model with two counter-rotating cylindrical brushes which convey the dirt into a collection box, speeding up maintenance and cleaning.
Request information

PRODUCT SPECIFICATIONS

Ride-on machine with traction Ride-on machine with traction
Power supply 36V/500Ah Power supply 36V/500Ah
Cleaning width 1000mm Cleaning width 1000mm
Brushes pressure adjustable - - - Brushes pressure adjustable - - -
Battery autonomy 5-7h Battery autonomy 5-7h
Solution tank / recovery tank 235/250l Solution tank / recovery tank 235/250l
Cylindrical brushes <br /> 1x150 mm <br /> 1x280 mm Cylindrical brushes
1x150 mm
1x280 mm
Brushes speed <br /> 933rpm <br /> 500rpm Brushes speed
933rpm
500rpm

According to 196/03 law, the collected data will be only used to inform customers about Adiatek S.r.l. activities and will be considered secret. Data introduction is optional, but we can’t give services without personal information. Owner of data treatment is Adiatek S.r.l. - Via Monte Pastello 14, 37057 San Giovanni Lupatoto (Verona) - Italy.

A ride-on sweeper machine with a cleaning width of 100 cm. Two cyllindrical brushes clean and collect the dirt in a recovery box that drains the exceeding water then collected by the squeegee with a 100cm cleaning width.

The "brush dry" system avoids the leaking at the end of the work.

The cleaning system is very efficient and despite the big dimension the maintenance is very easy to operate as the brushes can be taken on and off fastly.

This machine is particularli indicated for every fast maintenance cleaning and for large joints floors.

Thanks to its AC traction wheel, the diamond machine requires a reduced maintenance related to the motor, which goes hand in hand with great performances both when starting to drive and when driving over ramps.
Click here to download the product sheet
- Squeegee width: 1300 mm
- Brushes motor: 1800 Watt
- Motion system: automatic
- Maximum gradient: 10%
- Suction motor: 2x570 Watt
- Suction vacuum: 190 mbar
- Machine dimensions: L: 2025 mm
  W: 1165 mm
with rollbar H: 1685 mm
without rollbar H: 1330 mm
- Machine weight w/o battery: 670 kg
- Traction motor: 1400 Watt
- Movement speed: 9 km/h
- Battery compartment: L: 640 mm
  W: 655 mm
  H: 530 mm
- Class: III
- Protection level: IP X3
- Loudness: <70 dB (A)


Quick guide

There you can download the machine’s quick guide.
We always recommend to read the complete Use&Maintenance manual.

diamond 100s_IT quick guide

diamond 100s_EN quick guide

diamond 100s_F quick guide

diamond 100s_D quick guide

diamond 100s_E quick guide



Use & Maintenance manual

There you can download the Use & Maintenance manual.

Use & Maintenance_IT

Use & Maintenance_EN

Use & Maintenance_F

Use & Maintenance_D

Use & Maintenance_E
