jade 50

jade 50
Theoretical working capacity: 2250 m2/h
Single brush version with a cleaning path of 50 cm. The aluminium brush base is equipped with a reduction gear designed and manufactured by Adiatek, particularly durable and noiseless.
Request information

PRODUCT SPECIFICATIONS

Walk behind machine with traction Walk behind machine with traction
Power supply 24V/180Ah Power supply 24V/180Ah
Cleaning width 508mm Cleaning width 508mm
Brushes pressure adjustable max.36kg Brushes pressure adjustable max.36kg
Battery autonomy 3-5h Battery autonomy 3-5h
Solution tank / recovery tank 53/56l Solution tank / recovery tank 53/56l
Disc brush 1x508mm Disc brush 1x508mm
Brushes speed 165rpm Brushes speed 165rpm

According to 196/03 law, the collected data will be only used to inform customers about Adiatek S.r.l. activities and will be considered secret. Data introduction is optional, but we can’t give services without personal information. Owner of data treatment is Adiatek S.r.l. - Via Monte Pastello 14, 37057 San Giovanni Lupatoto (Verona) - Italy.

Single brush version with a cleaning width of 50 cm. The strong and silent aluminium brush base is provided with a geared motor designed by Adiatek.

This machine is suitable for all those situations where it is important the frequent cleaning of the brush as this model is provided with an automatic docking system for the bush that does not require the manual intervention.

The machine is perfect for hospital, schools and all the environments where the care for the hygiene is more important.


Click here to download the product sheet
- Squeegee width: 850 mm
- Brushes motor: 600 Watt
- Motion system: automatic
- Maximum gradient: 10%
- Suction motor: 400 Watt
- Suction vacuum: 120 mbar
- Machine dimensions: L: 1335 mm
W: 590 mm
H: 1078 mm
- Machine weight w/o battery: 101 kg
- Traction motor: 180 Watt
- Movement speed: 3.2-4.5 km/h
- Battery compartment: L: 405 mm
W: 390 mm
H: 374 mm
- Class: III
- Protection level: IP X3
- Loudness: 68.5 dB (A)

Quick guide

There you can download the machine’s quick guide.
We always recommend to read the complete Use&Maintenance manual.


jade 50_IT quick guide

jade 50_EN quick guide

jade 50_F quick guide

jade 50_D quick guide

jade 50_E quick guide



Use & Maintenance manual

There you can download the Use & Maintenance manual.


Use & Maintenance_IT

Use & Maintenance_EN

Use & Maintenance_F

Use & Maintenance_D

Use & Maintenance_E
