coral 65 ll

coral 65 ll
Theoretical working capacity: 3300 m2/h
Compact 24V ride-on scrubbing machine available with two counterrotating brushes, two reduction gears and a working width of 65 cm.
Request information

PRODUCT SPECIFICATIONS

Ride-on machine with traction Ride-on machine with traction
Power supply 24V/240Ah Power supply 24V/240Ah
Cleaning width 660mm Cleaning width 660mm
Brushes pressure adjustable max. 80kg Brushes pressure adjustable max. 80kg
Battery autonomy </br>3-4h Battery autonomy
3-4h
Solution tank / recovery tank 100/105l Solution tank / recovery tank 100/105l
Disc brushes 2x345mm Disc brushes 2x345mm
Brushes speed 170rpm Brushes speed 170rpm

According to 196/03 law, the collected data will be only used to inform customers about Adiatek S.r.l. activities and will be considered secret. Data introduction is optional, but we can’t give services without personal information. Owner of data treatment is Adiatek S.r.l. - Via Monte Pastello 14, 37057 San Giovanni Lupatoto (Verona) - Italy.

Ride-on scrubber, compact, 24V batteries powered and equipped with a double counterrotating brushes brush base with two geared motors and a cleaning width 65 cm.

The polyethylene tanks are very thick and ensure a 100 liters detergent solution capacity.

The battery van allows to store batteries up to 240Ah for a 5 hours autonomy which is optimal for surfaces up 3300 m2/h.

The driving seat is ergonomic, provided with digital controls and it indicates the setting and the battery level, the hours the machine worked and the brush pressure set.


Click here to download the product sheet
- Squeegee width: 1000 mm
- Brushes motor: 900 Watt
- Motion system: automatic
- Maximum gradient: 10%
- Suction motor: 580 Watt
- Suction vacuum: 160 mbar
- Machine dimensions: L: 1575 mm
  W: 730 mm
  H: 1320 mm
- Machine weight w/o battery: 277 kg
- Traction motor: 500 Watt
- Movement speed: 5 km/h
- Battery compartment: L: 520 mm
  W: 415 mm
  H: 385 mm
- Class: III
- Protection level: IP 23
- Loudness: 65.9 dB (A)

Quick guide

There you can download the machine’s quick guide.
In the video area you can find also a movie version of the machine’s quick guide.
We always recommend to read the complete Use&Maintenance manual.

coral 65II_IT quick guide

coral 65II_EN quick guide

coral 65II_F quick guide

coral 65II_D quick guide

coral 65II_E quick guide



Use & Maintenance manual

There you can download the Use & Maintenance manual.

Use & Maintenance_IT

Use & Maintenance_EN

Use & Maintenance_F

Use & Maintenance_D

Use & Maintenance_E
