coral 70s

coral 70s
Theoretical working capacity: 3500 m2/h
A 24V ride-on machine with cylindrical brushes and a working width of 70 cm.
It can be equipped with


Ride-on machine with traction Ride-on machine with traction
Power supply 24V/240Ah Power supply 24V/240Ah
Cleaning width 700mm Cleaning width 700mm
Brushes pressure adjustable - - - Brushes pressure adjustable - - -
Battery autonomy 3,5-4,5h Battery autonomy 3,5-4,5h
Solution tank / recovery tank 100/105l Solution tank / recovery tank 100/105l
Cylindrical brushes 2x150mm Cylindrical brushes 2x150mm
Brushes speed 785rpm Brushes speed 785rpm
A ride-on sweeper machine with a cleaning width of 70 cm.

Two cyllindrical brushes clean and collect the dirt in a recovery box that drains the exceeding water then collected by the squeegee. The "brush dry" system avoids the leaking at the end of the work.

Every model features the "automatic" mode that runs all the machine functions and also the "break washing" mode which optimizes the end of the cleaning with a proper automatic shutdown sequence. The operator is able to work using only one button. Also the pressure that the brushes apply on the floor is adjustable on different levels independently from the brushes wearing.

The Coral model is suitable for every fast cleaning situation and for floors with large joints.

- Squeegee width: 1000 mm
- Brushes motor: 2x600 Watt
- Motion system: automatic
- Maximum gradient: 10%
- Suction motor: 800 Watt
- Suction vacuum: 160 mbar
- Machine dimensions: L: 1575 mm
  W: 780 mm
  H: 1320 mm
- Machine weight w/o battery: 262 kg
- Traction motor: 500 Watt
- Movement speed: 5 km/h
- Battery compartment: L: 520 mm
  W: 415 mm
  H: 385 mm
- Class: III
- Protection level: IP 23
- Loudness: <70 dB (A)

Quick guide

There you can download the machine’s quick guide.
In the video area you can find also a movie version of the machine’s quick guide.
We always recommend to read the complete Use&Maintenance manual.
coral 70s_EN quick guide


Use & Maintenance manual

There you can download the Use & Maintenance manual.
Use & Maintenance manual
