jade 50 orbital

jade 50 orbital
Theoretical working capacity: 2250 m2/h
Orbital head base version with a cleaning path of 50 cm.
Request information

PRODUCT SPECIFICATIONS

Walk behind machine with traction Walk behind machine with traction
Power supply 24V/180Ah Power supply 24V/180Ah
Cleaning width 508mm Cleaning width 508mm
Battery autonomy 3-5h Battery autonomy 3-5h
Solution tank / recovery tank 53/56l Solution tank / recovery tank 53/56l
Adjustable pad pressure max.50kg Adjustable pad pressure max.50kg
Pad measurements 500x350mm Pad measurements 500x350mm

According to 196/03 law, the collected data will be only used to inform customers about Adiatek S.r.l. activities and will be considered secret. Data introduction is optional, but we can’t give services without personal information. Owner of data treatment is Adiatek S.r.l. - Via Monte Pastello 14, 37057 San Giovanni Lupatoto (Verona) - Italy.

The jade orbital 50 is built on the jade body that was rigorously tested during years. Its simple design and durable construction offers an unmatched value for the customer. This automatic battery scrubber has a stronger traction motor of 400W in order to climb steep ramps without the need to push it.
While keeping with the constant durability that Adiatek machines offer, your operators will find the jade orbital scrubber easy to move through narrow areas and easy to maintain. The strong deck is protected by large PPL rollers in order to keep the unit safe from marking walls.
The jade orbital machines offer an unbeatable floor cleaning result every time you want to finish any floor thanks to its powerful 750W brush motor. The equipment reduces slip & fall accidents as well as a reduction of soap and water usage.
  • Great for compact areas.
  • Easy weight adjustment from 35kg / 77lbs up to 50kg / 110lbs.
  • Reduced vibrations to the operator’s hands thanks to isolators.
  • Rectangular scrub head reaches into corners and hard-to-reach areas easily for even floor finish removal across the entire cleaning path.
  • Provides power and performance without the risks of chemicals.

Click here to download the product sheet
- Squeegee width: 770 mm
- Brushes motor: 750 Watt
- Motion system: automatic
- Maximum gradient: 10%
- Suction motor: 400 Watt
- Suction vacuum: 120 mbar
- Machine dimensions: L: 1244 mm
W: 548 mm
H: 1098 mm
- Machine weight w/o battery: 119 kg
- Traction motor: 400 Watt
- Movement speed: 3.2-4.5 km/h
- Battery compartment: L: 405 mm
W: 390 mm
H: 399 mm
- Class: III
- Protection level: IP X3
- Loudness: <70 dB (A)

Use & Maintenance manual

There you can download the Use & Maintenance manual.


Use & Maintenance_IT

Use & Maintenance_EN

Use & Maintenance_F

Use & Maintenance_D

Use & Maintenance_E
