ruby 55t
ruby 55truby 55truby 55truby 55truby 55truby 55truby 55t
Ruby

ruby 55t

It is a floor cleaning machine provided with a two counterrotating brushes brush base with a cleaning width of di 55 cm. The two models differ from each other for the presence of the electric traction system.

The weight applied on the brushes is adjustable by the operator depending on the type of floors to clean.

In the traction version it is possible to adjust the brushes angle in order to have them also helping the traction. Thanks to its strong structure, the easy maintenance and the simple controls, working with Ruby becomes very simple having also a hight cleaning quality.
Theoretical productivity: 2200 m2/h
Characteristics
Walk behind machine with or without traction
Walk behind machine with or without traction
Power supply 24V/110Ah
Power supply 24V/110Ah
Cleaning width 550mm
Cleaning width 550mm
Brushes pressure adjustable max.24,5kg
Brushes pressure adjustable max.24,5kg
Battery autonomy 2-4h
Battery autonomy 2-4h
Solution tank / recovery tank 40/45 l
Solution tank / recovery tank 40/45 l
Disc brushes 2x285mm
Disc brushes 2x285mm
Brushes speed 280rpm
Brushes speed 280rpm
Technical data
Squeegee width
770 mm
Brushes motor
420 Watt
Motion system
automatic
Maximum gradient
2%
Suction motor
570 Watt
Suction vacuum
120 mbar
Machine length
1140 mm
Machine width
586 mm
Machine height
1053 mm
Machine weight w/o battery
84 kg
Traction motor
120 Watt
Maximum forward speed
4 km/h
Batteries compartment length
350 mm
Batteries compartment width
342 mm
Batteries compartment height
295 mm
Class
|||
Protection level
IP 23
oudness
67.6 dB (A)
Video
Please accept preferences, statistics, marketing cookies to see this content
Brushes and pad holder
Brushes
Material: Nylon<br />Ø brush: 285 mm<br />Ø bristle: 0,5 mm <br />Cod: 48901140
Material: Nylon
Ø brush: 285 mm
Ø bristle: 0,5 mm
Cod: 48901140
Material: PPL<br />Ø brush: 285 mm<br />Ø bristle: 0,3 mm <br />Cod: 48901110
Material: PPL
Ø brush: 285 mm
Ø bristle: 0,3 mm
Cod: 48901110
Material: PPL<br />Ø brush: 285 mm<br />Ø bristle: 0,6 mm <br />Cod: 48901150
Material: PPL
Ø brush: 285 mm
Ø bristle: 0,6 mm
Cod: 48901150
Material: PPL<br />Ø brush: 285 mm<br />Ø bristle: 0,9 mm <br />Cod: 48901170
Material: PPL
Ø brush: 285 mm
Ø bristle: 0,9 mm
Cod: 48901170
Material: Mix 5<br />Ø brush: 285 mm <br />Cod: 48901180
Material: Mix 5
Ø brush: 285 mm
Cod: 48901180
Material: abrasive bristles<br />Ø brush: 285 mm <br />Ø bristle: 1.2 mm <br />Cod: 48901160
Material: abrasive bristles
Ø brush: 285 mm
Ø bristle: 1.2 mm
Cod: 48901160
Pad Holder
Pad holder cl black <br />Ø disc: 280 mm <br />Cod: 48801020
Pad holder cl black
Ø disc: 280 mm
Cod: 48801020
Batteries and chargers
12V 85Ah5 AGM battery
12V 85Ah5 AGM battery
12V 77Ah5 gel battery
12V 77Ah5 gel battery
12V 105Ah5 gel battery
12V 105Ah5 gel battery
12V 110Ah5 tubular battery
12V 110Ah5 tubular battery
Lithium battery 24V 60Ah
Lithium battery 24V 60Ah
Battery charger 24V/12A high frequency lead and gel
Battery charger 24V/12A high frequency lead and gel
Standard lead 24V/15A battery charger (110Ah)
Standard lead 24V/15A battery charger (110Ah)
Battery charger with Schuko plug
Battery charger with Schuko plug
Battery charger on board
Battery charger on board
Accessories
Hose water load
Hose water load
Cap with hose for the water loading
Cap with hose for the water loading
Elastic for traction (55t)
Elastic for traction (55t)
Stainless steel chain for the recovery tank cap
Stainless steel chain for the recovery tank cap
Stainless steel chain for the solution tank cap
Stainless steel chain for the solution tank cap
Solution drain ruby
Solution drain ruby
Key switch
Key switch
Overcharge protection
Overcharge protection
External speed adjuster (55t)
External speed adjuster (55t)
Opt speed selection (55t)
Opt speed selection (55t)
Silenced suction motor
Silenced suction motor
